The Mavic Pro Platinum features a sleek design and compact body that is both powerful and alluring. A new and improved 30-minute flight time coupled with 60% noise power reduction makes the Mavic Pro Platinum DJI’s best portable drone yet.
Aircraft noise has been reduced by up to 4dB* (60% noise power) and extended flight time to 30 minutes with new FOC sinusoidal driver ESCs and 8331 propellers for a quieter, more enjoyable flight experience.
With a brand-new aerodynamic design, the 8331 propellers give the Mavic Pro Platinum an impressive noise control performance,and the new FOC ESC drivers offer sinusoidal current for increased stability.
| Folded | H83mm x W83mm x L198mm |
|---|---|
| Diagonal Size (Propellers Excluded) | 335 mm |
| Weight (Battery & Propellers Included) | 1.62 lbs (734 g) (exclude gimbal cover) 1.64 lbs (743 g) (include gimbal cover) |
| Max Ascent Speed | 16.4 ft/s (5 m/s) in Sport mode |
| Max Descent Speed | 9.8 ft/s (3 m/s) |
| Max Speed | 40 mph (65 kph) in Sport mode without wind |
| Max Service Ceiling Above Sea Level | 16404 feet (5000 m) |
| Max Flight Time | 30 minutes (no wind at a consistent 15.5 mph (25 kph)) |
| Max Hovering Time | 27 minutes (no wind) |
| ESC(Electronic Speed Controller) | FOC |
| Max Flight Distance | 9.3 mi (15 km, no wind) |
| Operating Temperature Range | 32° to 104° F (0° to 40° C) |
| Satellite Positioning Systems | GPS / GLONASS |
| Hover Accuracy Range | Vertical: +/- 0.1 m (when Vision Positioning is active) or +/-0.5 m Horizontal: +/- 0.3 m (when Vision Positioning is active) or +/-1.5 m |
| Operating Frequency | FCC: 2.4-2.4835GHz; 5.150-5.250 GHz; 5.725-5.850 GHz CE: 2.4-2.4835GHz; 5.725-5.850 GHz SRRC： 2.4-2.4835 GHz;5.725-5.850 GHz |
| Transmitter Power (EIRP) | 2.4GHz FCC:<=26 dBm; CE: <=20 dBm; SRRC:<=20 dBm; MIC:<=18 dBm 5.2 GHz FCC:<=23 dBm 5.8 GHz FCC:<=23 dBm; CE <=13 dBm; SRRC: <=23 dBm; MIC: - |
| Operating Frequency | 2.4 GHz to 2.483 GHz |
|---|---|
| Max Transmission Distance | FCC Compliant: 4.3 mi (7 km); CE Compliant: 2.5 mi (4 km) SRRC Compliant: 2.5mi (4 km) MIC Compliant: 2.5 mi (4 km) (Unobstructed, free of interference) |
| Operating Temperature Range | 32° to 104° F ( 0° to 40° C ) |
| Battery | 2970mAh |
| Transmitter Power (EIRP) | FCC：<=26 dBm CE：<=20 dBm SRRC: <=20 dBm MIC: <=18 dBm |
| Operating Current/Voltage | 950mA @ 3.7V |
| Supported Mobile Device Size | Thickness Supported:6.5-8.5mm Max length: 160mm Supported USB port types: Lightning, Micro USB(Type-B),USB(Type-C)™ |
| Controllable Range | Pitch: -90° to +30° Roll: 0° or 90° (Horizontally and vertically) |
|---|---|
| Stabilization | 3-axis (pitch, roll, yaw) |
| Vision System | Forward Vision System Downward Vision System |
|---|---|
| Obstacle Sensory Range | Precision measurement range: 2 ft (0.7 m) to 49 ft (15 m) Detectable range: 49 ft (15 m) to 98 ft (30 m) |
| Operating Environment | Surface with clear pattern and adequate lighting (lux > 15) |
| Velocity Range | ≤22.4 mph (36 kph) at 6.6 ft (2 m) above ground |
| Altitude Range | 1 - 43 feet (0.3 - 13 m) |
| Operating Range | 1 - 43 feet (0.3 - 13 m) |
| Mobile App | DJI GO 4 |
|---|---|
| Live View Quality | 720p@30fps, 1080p@30fps（Remote Controller） 720p@30fps(Wi-Fi) 720p@60fps, 1080p@30fps（DJI Goggles） |
| Latency | 160-170ms (depending on conditions and mobile device) |
| Required Operating Systems |
|
